IP Configuration

Configure your PC's IP settings to access the receiver's configuration server

---

The configuration of the sensors will be done from the server embedded in the receiver. It will therefore be necessary for you to be able to access the configuration interface of your RX MOBDUS or RX BACNET. The receiver configuration server is accessible at the address 192.168.77.77

Configuring IP settings from your PC

On your PC, configure the IP settings so that the configuration server is accessible.

Example of IP settings

• IP address: 192.168.77.2

• Subnet prefix length: 24

• Default gateway: 192.168.77.1

• Preferred DNS: 8.8.8.8

• Subnet mask (if available): 255.255.255.0

Once these settings are configured, the configuration server IP should be accessible from your browser at 192.168.77.77 (please avoid use on Microsoft Edge and favor use on Google Chrome).

You can now move on to the next step.

This configuration is also valid for access to the configuration servers of the TX IO and TX MODBUS .
